БЛОК СМЕШИВАНИЯ И РАЗБАВЛЕНИЯ SLES

0 отзывов
Производитель
Tapflo
Характеристики
  • Описание
  • Характеристики
  • Доставка и оплата
  • Отзывы

SLES* is an organic chemical compound with excellent cleansing and foaming properties. For this reason it is an ingredient of various detergents, household products, soaps and shampoos.

SLES is usually supplied to the producers of above liquids at a concentration of 70%.

Due to its physical properties, this concentrated solution is difficult to handle and must be diluted below 27% before using it in the process.

Features

  • Continous or batch supply of SLES solution at a given concentration
  • Immediate start of mixing process
  • Constant tracing and recording of operation parameters
  • Small in size, lightweight and well thought-out construction
  • Local or remote control over the Unit
  • Possible extensions: dosing of additional ingredients, feeding 70% SLES solution directly from a road tanker

Benefits

  • Independence from deliveries of diluted SLES
  • Flexibility and continuity of production
  • High quality of the on-site prepared SLES solution
  • Significant costs reduction of SLES purchase, transportation and storage
  • Additional savings on the warehouse space
  • Simple and user-friendly control system


Technical data

Flow rate (SLES solution): up to 30 m3/h, various sizes available
Discharge pressure: up to 6 bar-g
Concentration of obtained SLES solution: 0 - 27 %

Design and materials

Pumps:
  • Progressive Cavity Pump for 70% SLES solution feed
  • Centrifugal Pump for mixing SLES with water and pumping the solution
Control and automation:
  • Control Unit including PLC with a touch screen
  • Pressure transmitters
  • Temperature transmitte
  • Frequency inverters
  • Flowmeters
  • Valves with dedicated control system
Piping:
  • AISI 316 stainless steel
Frame:
  • AISI 304 stainless steel



ПРИНЦИП РАБОТЫ

Вязкость SLES

Инновационный блок смешивания и разбавления SLES, разработанный Tapflo, позволяет немедленно и точно приготовить менее концентрированный раствор SLES. Это устройство дает полный контроль над процессом разбавления, обеспечивая гомогенность и стабильность SLES во времени.

SLES с постоянным перемешиванием

Завод
Tapflo
